DT Swiss

DT Swiss - PHR Washers

DT Swiss - PHR Washers

$35.90 NZD
$0.00 NZD $35.90 NZD
Rouleur Online Price Sold out
Taxes included. Shipping calculated at checkout.
Stock Item

In stock

  • NZ Based
    NZ‑Based Support – Talk to real riders who understand your needs.
  • Secure Payments
    Secure Payments – Shop Pay, Google Pay, Apple Pay & major cards accepted.
  • Warranty Protection
    Warranty Protection – All bikes backed by manufacturer warranties.
  • Easy Returns
    Easy Returns – Hassle‑free returns on unused gear.

DT SWISS - PHR WASHERS

Pro Head Rim (PHR) washers have a unique shape, specifically a hyperbolic paraboloid. With this shape, the load-bearing surface of the nipples on the rim is increased and stress concentrations at the rim holes are reduced. The shape of the PHR washer automatically aligns the specific DT Swiss Squorx (Pro Head) nipples, and together they act as a ball joint, further reducing the risk of spoke failure and rim cracking.

Please note that the PHR washers are specifically designed to fit DT Swiss rims (including the RR, GR, HX, EX, MX and XR Premium/non eyelet rims). Although the shape of the washer may be compatible with similar rim profiles, they are not recommended for use on other rims.

When installing the PHR washers, please ensure that the washers sit straight in the rim cavity. The two dots on the underside face of the washers will help to identify their orientation. You may need to use a torch to ensure the washers are correctly seated.

DT Swiss PHR washers are designed for use with DT Swiss Pro Head nipples, with a ball-shape head.

Compatibility:
